48-KHz, 2-channel USB Audio Interface with 2 Combo Inputs with Crystal Preamps, and Phantom Power
The M-Track Solo is the best, most portable recording interface in its class. It delivers 48 kHz audio resolution in a compact and easy to use format that is ideal for creating music on any Mac, PC or iOS device. This versatile interface works great for recording any type of sound source and features a single Combo Crystal Preamp with phantom power, plus a switchable Line / Instrument input making it compatible with any guitar or microphone. Plus, with M-Track Solo's 2-channel recording you can use both line inputs simultaneously to capture digital pianos, drum machines or any other stereo 1/4" device. M-track Solo is completely powered by USB, removing the need for an external power supply and making it perfectly portable for recording on-the-go. Throw it into your bag, grab a laptop, and create your next podcast, song, or mix anywhere you want!
Key Features
2-Channel USB recording interface for Mac and PC
(2) Combo inputs with Crystal Preamps amazing audio quality
Dedicated switches to enable any microphone, instrument, or line level device
+48V phantom power for connecting studio condenser microphones
Stereo 1/4” outs; 1/4” headphone out with independent level controls
USB/Direct Mono/Direct Stereo switch for monitoring mic, line or instrument inputs in stereo or mono
Software bundle, including: MPC Beats, AIR Music Tech Electric, Bassline, and TubeSynth, Revalver guitar amp plugin and 80 AIR plugin effects
Technical Specifications
Mic Input (balanced XLR)
Frequency Response
20 Hz – 20 kHz (+0.1 dB)
Signal-to-Noise Ratio
109 dB (A-weighted)
THD+N
0.003% (min. gain, 0 dBu out, A-weighted)
Preamp EIN
-128 dBu (max. gain, 40 Ω source, A-weighted)
Gain Range
Direct Mono: 0 dB to +54 dB Direct Stereo: 6 dB to +60 dB
Line Input (balanced 1/4" [6.35 mm] TRS)
Frequency Response
20 Hz – 20 kHz (+0.1 dB)
Sensitivity
-43 dBu
THD
0.002% (min. gain, 0 dBu out, A-weighted)
Gain Range
Direct Mono: -10 dB to +44 dB Direct Stereo: -4 dB to +50 dB
Instrument Input (unbalanced 1/4" [6.35 mm] TS)
Frequency Response
20 Hz – 20 kHz (+0.1 dB)
THD+N
0.005% (min. gain, 0 dBu out, A-weighted)
Input Impedance
1 MΩ
Gain Range
Direct Mono: -10 dB to +44 dB Direct Stereo: -4 dB to +50 dB
Main Outputs, L and R (impedance-balanced 1/4" [6.35 mm] TRS)
Frequency Response
20 Hz – 20 kHz (+0.1 dB)
Signal-to-Noise Ratio
109 dB (A-weighted)
THD
0.002% (0 dBu out, A-weighted)
Max Output Level
+4 dBu
Headphone Output (1/4” [6.35 mm] TRS)
Power
60 mW/Ch, 32 Ω
Frequency Response
20 Hz – 20 kHz (+0.5 dB)
THD+N
0.02% (A-weighted)
Signal-to-Noise Ratio
100 dB (A-weighted)
What’s In The Box
M-Track Duo USB-B–to–USB-A Cable Software Download Cards User Guide
